National Instruments PCI-1422 Digital Image Acquisition Board
- Brand
- National Instruments
- Model
- PCI-1422
- GEARWELL SKU
- GWP-000026397
- Category
- Machine Safety & Vision
Key specifications
- Bus
- PCI
- Driver
- NI-IMAQ (NI Vision Acquisition Software)
- Evidence
- National Instruments 372158D-01 NI PXI/PCI-1422 User Manual (hosted at apexwaves.com)
- Onboard memory
- 32 MB SDRAM
- Max pixel clock
- 40 MHz
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | National Instruments PCI-1422 Digital Image Acquisition Board |
|---|---|
| Brand | National Instruments |
| Model | PCI-1422 |
| Category | Machine Safety & Vision |
| Bus | PCI |
| Driver | NI-IMAQ (NI Vision Acquisition Software) |
| Evidence | National Instruments 372158D-01 NI PXI/PCI-1422 User Manual (hosted at apexwaves.com) |
| Onboard memory | 32 MB SDRAM |
| Max pixel clock | 40 MHz |
| Video data width | up to 16 bits, differential |
| External I/O lines | 4 (trigger or digital I/O) |
| Camera control lines | 4 |
