National Instruments cFP-DO-403 FieldPoint Digital Output Module
- Brand
- National Instruments
- Model
- cFP-DO-403
- GEARWELL SKU
- GWP-000026418
- Category
- PLCs & I/O
Key specifications
- Channels
- 16 sinking digital outputs
- Evidence
- National Instruments 373354C-01 FP-DO-403 and cFP-DO-403 Operating Instructions and Specifications (hosted at apexwaves.com)
- Isolation
- 250 Vrms CAT II continuous channel-to-ground
- Hot swappable
- Yes
- Voltage range
- 5 to 30 VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | National Instruments cFP-DO-403 FieldPoint Digital Output Module |
|---|---|
| Brand | National Instruments |
| Model | cFP-DO-403 |
| Category | PLCs & I/O |
| Channels | 16 sinking digital outputs |
| Evidence | National Instruments 373354C-01 FP-DO-403 and cFP-DO-403 Operating Instructions and Specifications (hosted at apexwaves.com) |
| Isolation | 250 Vrms CAT II continuous channel-to-ground |
| Hot swappable | Yes |
| Voltage range | 5 to 30 VDC |
| Output current | 2 A per channel, 16 A per module |
| Operating temperature | -40 to 70 °C |
