Mitsubishi Electric FR-A842-10940-2-60 FR-A800 series (separated converter type) Inverter (separated converter type, DC input)
- Brand
- Mitsubishi Electric
- Model
- FR-A842-10940-2-60
- GEARWELL SKU
- GWP-000030151
- Category
- Variable Frequency Drives
Key specifications
- Approx. mass
- 243 kg
- Rated voltage
- Three-phase 380 to 500 V
- DC power supply voltage
- 430 to 780 VDC
- Rated output current HD
- 770 A
- Rated output current ND
- 866 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Mitsubishi Electric FR-A842-10940-2-60 FR-A800 series (separated converter type) Inverter (separated converter type, DC input) |
|---|---|
| Brand | Mitsubishi Electric |
| Model | FR-A842-10940-2-60 |
| Category | Variable Frequency Drives |
| Approx. mass | 243 kg |
| Rated voltage | Three-phase 380 to 500 V |
| DC power supply voltage | 430 to 780 VDC |
| Rated output current HD | 770 A |
| Rated output current ND | 866 A |
| Rated output current SLD | 1094 A |
| Applicable motor capacity ND | 450 kW |
| Applicable motor capacity SLD | 560 kW |
