MEANWELL LRS-150-24 LRS-150 Series 24V 156W Enclosed Power Supply
- Brand
- MEANWELL
- Model
- LRS-150-24
- GEARWELL SKU
- GWP-000021519
- Category
- Power Supplies
Key specifications
- Dimensions
- 159*97*30 (L*W*H) mm
- Rated power
- 156 W
- Rated current
- 6.5 A
- Efficiency (typ.)
- 89 %
- Output voltage
- 24 V dc
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | MEANWELL LRS-150-24 LRS-150 Series 24V 156W Enclosed Power Supply |
|---|---|
| Brand | MEANWELL |
| Model | LRS-150-24 |
| Category | Power Supplies |
| Dimensions | 159*97*30 (L*W*H) mm |
| Rated power | 156 W |
| Rated current | 6.5 A |
| Efficiency (typ.) | 89 % |
| Output voltage | 24 V dc |
| Withstand voltage | I/P-O/P:4KVAC, I/P-FG:2KVAC, O/P-FG:1.25KVAC |
| Input voltage range | 85 ~ 132VAC / 170 ~ 264VAC by switch / 240 ~ 370VDC(switch on 230VAC) |
| Working temperature | -30 ~ +70 (see derating curve) °C |
| Voltage adjustment range | 21.6 ~ 28.8 V |
