MEANWELL LPF-25-30 LPF-25 25W 30V LED Driver
- Brand
- MEANWELL
- Model
- LPF-25-30
- GEARWELL SKU
- GWP-000023220
- Category
- Power Supplies
Key specifications
- Rated power
- 25.2 W
- Rated current
- 0.84 A
- Output voltage
- 30 V
- Ingress protection
- IP67
- Input voltage range
- 90 ~ 305 VAC / 127 ~ 431 VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | MEANWELL LPF-25-30 LPF-25 25W 30V LED Driver |
|---|---|
| Brand | MEANWELL |
| Model | LPF-25-30 |
| Category | Power Supplies |
| Rated power | 25.2 W |
| Rated current | 0.84 A |
| Output voltage | 30 V |
| Ingress protection | IP67 |
| Input voltage range | 90 ~ 305 VAC / 127 ~ 431 VDC |
| Dimensions (L x W x H) | 148 x 40 x 32 mm |
| Constant current region | 16.5 ~ 30 V |
| Working case temperature | -35 ~ +70 °C |
