MEANWELL HLG-480H-C3500B HLG-480H-C 480W 3500mA LED Driver
- Brand
- MEANWELL
- Model
- HLG-480H-C3500B
- GEARWELL SKU
- GWP-000023218
- Category
- Power Supplies
Key specifications
- Rated power
- 480 W
- Dimming (B-Type)
- 3 in 1: 0-10 VDC, 10 V PWM, resistance
- Current adj. range
- 1750 ~ 3500 mA
- Input voltage range
- 90 ~ 305 VAC / 127 ~ 431 VDC
- Dimensions (L x W x H)
- 262 x 125 x 43.8 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | MEANWELL HLG-480H-C3500B HLG-480H-C 480W 3500mA LED Driver |
|---|---|
| Brand | MEANWELL |
| Model | HLG-480H-C3500B |
| Category | Power Supplies |
| Rated power | 480 W |
| Dimming (B-Type) | 3 in 1: 0-10 VDC, 10 V PWM, resistance |
| Current adj. range | 1750 ~ 3500 mA |
| Input voltage range | 90 ~ 305 VAC / 127 ~ 431 VDC |
| Dimensions (L x W x H) | 262 x 125 x 43.8 mm |
| Rated output current | 3500 mA |
| Constant current region | 68 ~ 137 V |
| Working case temperature | -40 ~ +90 °C |
