LENZE EMF2133IB PROFIBUS-DP AIF Communication Module
- Brand
- LENZE
- Model
- EMF2133IB
- GEARWELL SKU
- GWP-000015730
- Category
- Industrial Communication
Key specifications
- Baud rate
- 9.6 ... 12000 (automatic detection) kbps
- Interface
- RS485, 9-pin Sub-D socket
- Max. stations
- 32 (125 with repeater)
- Order designation
- EMF2133IB
- External DC supply
- 24 V DC ±10 %, 120 mA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | LENZE EMF2133IB PROFIBUS-DP AIF Communication Module |
|---|---|
| Brand | LENZE |
| Model | EMF2133IB |
| Category | Industrial Communication |
| Baud rate | 9.6 ... 12000 (automatic detection) kbps |
| Interface | RS485, 9-pin Sub-D socket |
| Max. stations | 32 (125 with repeater) |
| Order designation | EMF2133IB |
| External DC supply | 24 V DC ±10 %, 120 mA |
| Process data words | 1 ... 12 |
| Communication profile | PROFIBUS-DP-V0, PROFIBUS-DP-V1 |
