KINCO FD422S-LF-000 FD2S Series AC Servo Drive
- Brand
- KINCO
- Model
- FD422S-LF-000
- GEARWELL SKU
- GWP-000021636
- Category
- Servo Systems
Key specifications
- Series
- FD2S servo driver (upgrade version of FD2)
- Weight
- 1.2 kg
- Digital I/O
- 7 digital inputs / 5 digital outputs
- Analog inputs
- 2 (-10 V to +10 V)
- Cooling method
- Fan
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KINCO FD422S-LF-000 FD2S Series AC Servo Drive |
|---|---|
| Brand | KINCO |
| Model | FD422S-LF-000 |
| Category | Servo Systems |
| Series | FD2S servo driver (upgrade version of FD2) |
| Weight | 1.2 kg |
| Digital I/O | 7 digital inputs / 5 digital outputs |
| Analog inputs | 2 (-10 V to +10 V) |
| Cooling method | Fan |
| Protection class | IP20 |
| Communication ports | RS232, RS485 (Modbus RTU) |
| Input voltage class | AC 220 V |
| Peak current (FD422S-□F-000) | 15 A |
| Matching motors (selection table) | SMG130D 1.0-2.0 kW (130 flange) |
