KINCO 2S86Q-85B8 Two-Phase Hybrid Stepper Motor, 86 mm, 8.5 N·m
- Brand
- KINCO
- Model
- 2S86Q-85B8
- GEARWELL SKU
- GWP-000022833
- Category
- Motors & Gearboxes
Key specifications
- Step angle
- 1.8 °
- Flange size
- 86 mm
- Rotor inertia
- 3.4 kg·cm²
- Holding torque
- 8.5 N·m
- Number of leads
- 4
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KINCO 2S86Q-85B8 Two-Phase Hybrid Stepper Motor, 86 mm, 8.5 N·m |
|---|---|
| Brand | KINCO |
| Model | 2S86Q-85B8 |
| Category | Motors & Gearboxes |
| Step angle | 1.8 ° |
| Flange size | 86 mm |
| Rotor inertia | 3.4 kg·cm² |
| Holding torque | 8.5 N·m |
| Number of leads | 4 |
| Number of phases | Two-phase |
| Phase inductance | 6 ±20% mH |
| Phase resistance | 0.6 ±10% Ω |
| Motor length / weight | 118 mm / 3.7 kg |
| Shaft diameter / type | 13 mm / flat key |
| Phase current (series / parallel) | 6 / 6 A |
