KINCO FD423-LA-000 FD423 Series AC Servo Drive, 400-750 W, 220 VAC
- Brand
- KINCO
- Model
- FD423-LA-000
- GEARWELL SKU
- GWP-000022834
- Category
- Servo Systems
Key specifications
- Evidence
- Distributor only: Anaheim Automation (Kinco US distributor) spec sheet L011770 KNC-SRV-FD423 Series
- Communication
- RS232, RS485 (MODBUS); CAN on FD423-CA-000
- Control modes
- Position, speed, torque
- Input voltage
- Single-phase 180-264 VAC
- Matching motors
- SMS60S-0040, SMS80S-0075 (-3LKU)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KINCO FD423-LA-000 FD423 Series AC Servo Drive, 400-750 W, 220 VAC |
|---|---|
| Brand | KINCO |
| Model | FD423-LA-000 |
| Category | Servo Systems |
| Evidence | Distributor only: Anaheim Automation (Kinco US distributor) spec sheet L011770 KNC-SRV-FD423 Series |
| Communication | RS232, RS485 (MODBUS); CAN on FD423-CA-000 |
| Control modes | Position, speed, torque |
| Input voltage | Single-phase 180-264 VAC |
| Matching motors | SMS60S-0040, SMS80S-0075 (-3LKU) |
| Programmable I/O | 7 inputs / 4 outputs |
| Motor power range | 400-750 W |
| Supported encoders | 17-bit magnetic single-turn, 20-bit single-turn communication, 16-bit multi-turn absolute |
| Ordering code (distributor) | KNC-SRV-FD423-LA-000 |
