KINCO SMS80S-0075-30KBK-3LKU SMS Series AC Servo Motor, 750 W, Brake
- Brand
- KINCO
- Model
- SMS80S-0075-30KBK-3LKU
- GEARWELL SKU
- GWP-000022835
- Category
- Servo Systems
Key specifications
- Brake
- Yes
- Encoder
- 16-bit multi-turn absolute communication encoder
- Voltage
- 220 VAC
- Evidence
- archived Kinco Automation site (kincoautomation.com, 2018) SMS80S-0075 product page; encoder and drive pairing from Anaheim L011770
- Rated power
- 750 W
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KINCO SMS80S-0075-30KBK-3LKU SMS Series AC Servo Motor, 750 W, Brake |
|---|---|
| Brand | KINCO |
| Model | SMS80S-0075-30KBK-3LKU |
| Category | Servo Systems |
| Brake | Yes |
| Encoder | 16-bit multi-turn absolute communication encoder |
| Voltage | 220 VAC |
| Evidence | archived Kinco Automation site (kincoautomation.com, 2018) SMS80S-0075 product page; encoder and drive pairing from Anaheim L011770 |
| Rated power | 750 W |
| Rated torque | 2.39 N·m |
| Length / weight | 172 mm / 3.5 kg |
| Rated current | 3.8 Arms |
| Matching drive | FD423-LA-000 / FD423-CA-000 |
| Rated / max speed | 3000 / 5000 rpm |
