KEYENCE FT-H20 FT Series Infrared Temperature Sensor Head
- Brand
- KEYENCE
- Model
- FT-H20
- GEARWELL SKU
- GWP-000022827
- Category
- Pressure, Flow & Temperature
Key specifications
- Type
- Mid to low temperature, mid-range
- Sight
- 2-point visible laser beam
- Weight
- Approx. 120 g
- Repeatability
- ±0.5 °C
- Detecting element
- Thermopile
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KEYENCE FT-H20 FT Series Infrared Temperature Sensor Head |
|---|---|
| Brand | KEYENCE |
| Model | FT-H20 |
| Category | Pressure, Flow & Temperature |
| Type | Mid to low temperature, mid-range |
| Sight | 2-point visible laser beam |
| Weight | Approx. 120 g |
| Repeatability | ±0.5 °C |
| Detecting element | Thermopile |
| Ambient temperature | -10 to 55 (no freezing) °C |
| Detecting wavelength | 8 to 14 µm |
| Rated temperature range | 0 to 500 °C |
| Displayable temperature range | -50 to +520 °C |
| Measuring distance / view diameter | 60/ø8.5, 120/ø6, 180/ø14.5 mm |
