JUMO 703564/1-23 ER8 External Relay Module
- Brand
- JUMO
- Model
- 703564/1-23
- GEARWELL SKU
- GWP-000022204
- Category
- PLCs & I/O
Key specifications
- Weight
- approx. 400 g
- Evidence
- JUMO operating manual B 70.3564.0 (hosted at docs.rs-online.com)
- Mounting
- DIN rail 35 x 7.5 mm / 15 mm / G-rail
- Protection
- IP20 to EN 60529
- Relay outputs
- 8 changeover contacts, 230 V AC 3 A resistive
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | JUMO 703564/1-23 ER8 External Relay Module |
|---|---|
| Brand | JUMO |
| Model | 703564/1-23 |
| Category | PLCs & I/O |
| Weight | approx. 400 g |
| Evidence | JUMO operating manual B 70.3564.0 (hosted at docs.rs-online.com) |
| Mounting | DIN rail 35 x 7.5 mm / 15 mm / G-rail |
| Protection | IP20 to EN 60529 |
| Relay outputs | 8 changeover contacts, 230 V AC 3 A resistive |
| Supply voltage | 23 = 110-240 V AC +10/-15 %, 48-63 Hz |
| Power consumption | approx. 8 VA |
| Basic type extension | 1 = relay outputs 3 A, 230 V AC |
