JUMO 703041/181-140-23/214 dTRON 316 Compact Controller
- Brand
- JUMO
- Model
- 703041/181-140-23/214
- GEARWELL SKU
- GWP-000022201
- Category
- Pressure, Flow & Temperature
Key specifications
- Version
- 8 = Standard, with factory settings
- Basic type
- 703041 = JUMO dTRON 316, format 48 mm x 48 mm
- Extra code
- 214 = Math and logic module
- Option slots
- 1-4-0 = option 1 analog input 2, option 2 analog output, option 3 not used
- Logic outputs
- 1 = 0/12 V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | JUMO 703041/181-140-23/214 dTRON 316 Compact Controller |
|---|---|
| Brand | JUMO |
| Model | 703041/181-140-23/214 |
| Category | Pressure, Flow & Temperature |
| Version | 8 = Standard, with factory settings |
| Basic type | 703041 = JUMO dTRON 316, format 48 mm x 48 mm |
| Extra code | 214 = Math and logic module |
| Option slots | 1-4-0 = option 1 analog input 2, option 2 analog output, option 3 not used |
| Logic outputs | 1 = 0/12 V |
| Supply voltage | 23 = 110-240 V AC -15/+10 %, 48-63 Hz |
| Controller structure | P; I; PD; PI; PID (2 sets of control parameters) |
