IFM IG512A Inductive Full-Metal Sensor
- Brand
- IFM
- Model
- IG512A
- GEARWELL SKU
- GWP-000001008
- Category
- Industrial Automation Parts
Key specifications
- Protection
- IP 67; (when used outside the hazardous area: IP 65, IP 67, IP 68, IP 69K)
- Product type
- Inductive full-metal sensor
- Sensing range
- 5 mm
- Output function
- normally closed
- Electrical design
- PNP
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm IG512A (IGK3005-APKG/AM/US104DPO/3G/3D) is an inductive full-metal proximity sensor in an M18 x 1 threaded housing 70 mm long, for flush mounting. Its rated sensing range is 5 mm, which ifm classes as an increased sensing range. The real sensing range is 5 mm ± 10% and the operating distance on steel is 0…4.05 mm. The PNP switching output is normally closed, rated at 100 mA and up to 100 Hz on 10…30 V DC, with reverse polarity and short-circuit protection. On other metals the distance is reduced by ifm's correction factors: 0.7 for stainless steel, 0.7 for brass, 0.5 for aluminum and 0.2 for copper. The sensor has a stainless steel (1.4404 / 316L) housing, connects through an M12 connector (A-coded, 3 gold-plated contacts) and is rated IP67 for -40…60 °C ambient. The sensing face withstands 100 bar. Two lock nuts are included.
Technical reference
| Product name | IFM IG512A Inductive Full-Metal Sensor |
|---|---|
| Brand | IFM |
| Model | IG512A |
| Category | Industrial Automation Parts |
| Protection | IP 67; (when used outside the hazardous area: IP 65, IP 67, IP 68, IP 69K) |
| Product type | Inductive full-metal sensor |
| Sensing range | 5 mm |
| Output function | normally closed |
| Electrical design | PNP |
| Operating voltage | 10...30 V DC |
| Ambient temperature | -40...60 °C |
| Current consumption | < 20 mA |
