IFM IE5362 Inductive Sensor
- Brand
- IFM
- Model
- IE5362
- GEARWELL SKU
- GWP-000001121
- Category
- Industrial Automation Parts
Key specifications
- Protection
- IP 65; IP 67; (with ifm socket duly screwed on)
- Product type
- Inductive sensor
- Sensing range
- 4 mm
- Output function
- normally open
- Electrical design
- PNP
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm IE5362 (IEB3004-BPKG/V4A/AS) is an inductive proximity sensor in an M8 x 1 threaded housing 50 mm long, for non-flush mounting. Its rated sensing range is 4 mm, which ifm classes as an increased sensing range. The real sensing range is 4 mm ± 10% and the operating distance on steel is 0…3.24 mm. The PNP switching output is normally open, rated at 100 mA and up to 800 Hz on 10…30 V DC, with reverse polarity and short-circuit protection. On other metals the distance is reduced by ifm's correction factors: 0.7 for stainless steel, 0.5 for brass, 0.5 for aluminum and 0.4 for copper. The sensor has a stainless steel (1.4404 / 316L) housing, connects through an M8 connector (A-coded, 3 contacts) and is rated IP65 and IP67 for -10…70 °C ambient. It has UL approval under file E174191. Two lock nuts are included.
Technical reference
| Product name | IFM IE5362 Inductive Sensor |
|---|---|
| Brand | IFM |
| Model | IE5362 |
| Category | Industrial Automation Parts |
| Protection | IP 65; IP 67; (with ifm socket duly screwed on) |
| Product type | Inductive sensor |
| Sensing range | 4 mm |
| Output function | normally open |
| Electrical design | PNP |
| Operating voltage | 10...30 V DC |
| Ambient temperature | -10...70 °C |
| Current consumption | < 10 mA |
