HONEYWELL TC-FPCXX2 Chassis Series A AC Power Supply Module
- Brand
- HONEYWELL
- Model
- TC-FPCXX2
- GEARWELL SKU
- GWP-000026289
- Category
- Power Supplies
Key specifications
- Evidence
- Honeywell EP03-110-400 V2 Jan 2012, Experion LS I/O Specifications (hosted at nordwel.com)
- Input power
- 150 VA, 92 W
- Weight (approx.)
- 1.1 kg
- Coated version
- TK-FPCXX2
- Frequency range
- 47-63 Hz
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HONEYWELL TC-FPCXX2 Chassis Series A AC Power Supply Module |
|---|---|
| Brand | HONEYWELL |
| Model | TC-FPCXX2 |
| Category | Power Supplies |
| Evidence | Honeywell EP03-110-400 V2 Jan 2012, Experion LS I/O Specifications (hosted at nordwel.com) |
| Input power | 150 VA, 92 W |
| Weight (approx.) | 1.1 kg |
| Coated version | TK-FPCXX2 |
| Frequency range | 47-63 Hz |
| Total output power | 70 W at 60 °C |
| Input voltage range | 85-132 VAC or 170-265 VAC (selectable) |
| Dimensions (L x D x H) | 11.2 x 14.5 x 14.0 cm |
| Maximum inrush current | 15 A |
| Backplane output current max. | 1.5 A @ 1.2 V; 4 A @ 3.3 V; 10 A @ 5.1 V; 2.8 A @ 24 V |
