HONEYWELL TC-IXR061 Chassis Series A 6-Ch RTD Input Module (Isolated)

Key specifications

Accuracy: 0.1% FS @ 25 °C
Evidence: Honeywell EP03-110-400 V2 Jan 2012, Experion LS I/O Specifications (hosted at nordwel.com)
Resolution: 16 bits across each input range
Coated version: TK-IXR061
Terminal block: TC-TBNH, 20-position

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	HONEYWELL TC-IXR061 Chassis Series A 6-Ch RTD Input Module (Isolated)
Brand	HONEYWELL
Model	TC-IXR061
Category	PLCs & I/O
Accuracy	0.1% FS @ 25 °C
Evidence	Honeywell EP03-110-400 V2 Jan 2012, Experion LS I/O Specifications (hosted at nordwel.com)
Resolution	16 bits across each input range
Coated version	TK-IXR061
Terminal block	TC-TBNH, 20-position
Number of points	6 galvanically isolated channels
Power dissipation	4.3 W max
Sensors supported	Pt 100/200/500/1000 (α 0.00385, 0.003916), Ni 120 / 100-500, Cu 10 Ω
Module update rate	50 ms
Signal input ranges	1-487 Ω, 2-1000 Ω, 4-2000 Ω, 8-4020 Ω
