ABB JSBR4 230 VAC Jokab Safety JSBR4 Safety relay (2TLA010002R0500)
- Brand
- ABB
- Model
- JSBR4 230 VAC
- GEARWELL SKU
- GWP-000029304
- Category
- Machine Safety & Vision
Key specifications
- Power supply
- 230 VAC ± 15%, 50-60 Hz
- Safety level
- PL e, SIL 3, Category 4
- Relay outputs
- 3 NO + 1 NC
- Protection class
- IP40 / IP20
- Power consumption
- 1.3 W / 3.3 VA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ABB JSBR4 230 VAC Jokab Safety JSBR4 Safety relay (2TLA010002R0500) |
|---|---|
| Brand | ABB |
| Model | JSBR4 230 VAC |
| Category | Machine Safety & Vision |
| Power supply | 230 VAC ± 15%, 50-60 Hz |
| Safety level | PL e, SIL 3, Category 4 |
| Relay outputs | 3 NO + 1 NC |
| Protection class | IP40 / IP20 |
| Power consumption | 1.3 W / 3.3 VA |
| Operating temperature | -10 to +55 °C |
| Response time at deactivation | < 20 ms (145 ms at power loss) |
| Max. switching capacity, resistive AC | 6 A / 250 VAC / 1500 VA |
