HEIDENHAIN UVR 150 D Regenerative Supply Unit, 55 kW
- Brand
- HEIDENHAIN
- Model
- UVR 150 D
- GEARWELL SKU
- GWP-000026468
- Category
- Servo Systems
Key specifications
- ID
- 1080611-xx
- Mass
- 20 kg
- Cooling
- Air
- Evidence
- HEIDENHAIN brochure 'Inverter Systems' 622420-2C, 09/2017 (hosted at heidenhain.us)
- Power loss
- 640 W
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HEIDENHAIN UVR 150 D Regenerative Supply Unit, 55 kW |
|---|---|
| Brand | HEIDENHAIN |
| Model | UVR 150 D |
| Category | Servo Systems |
| ID | 1080611-xx |
| Mass | 20 kg |
| Cooling | Air |
| Evidence | HEIDENHAIN brochure 'Inverter Systems' 622420-2C, 09/2017 (hosted at heidenhain.us) |
| Power loss | 640 W |
| Seller code | UVR150D |
| Module width | 200 mm |
| Supply voltage | 3AC 400 V (±10 %), 50 to 60 Hz |
| DC-link voltage | 650 V DC |
| Peak power (DC link) | 80 kW (S6-40 %); 110 kW (0.2 s) |
| Rated power (DC link) | 55 kW |
| Integrated 24 V supply | 24 V NC / 400 W |
