HEIDENHAIN 334 756-03 LS 403C Sealed Linear Encoder ML 370 mm
- Brand
- HEIDENHAIN
- Model
- 334 756-03
- GEARWELL SKU
- GWP-000023240
- Category
- Encoders & Position
Key specifications
- Accuracy
- ±0.003 mm
- ID number
- 334756-03
- Power supply
- 5 V
- Signal period
- 0.020 mm
- Output signals
- Sinusoidal current signals 11 µApp
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HEIDENHAIN 334 756-03 LS 403C Sealed Linear Encoder ML 370 mm |
|---|---|
| Brand | HEIDENHAIN |
| Model | 334 756-03 |
| Category | Encoders & Position |
| Accuracy | ±0.003 mm |
| ID number | 334756-03 |
| Power supply | 5 V |
| Signal period | 0.020 mm |
| Output signals | Sinusoidal current signals 11 µApp |
| Reference marks | Distance-coded |
| Measuring length | 370 mm |
| Successor product ID | 560526-07 (LS 487C) |
| Electrical connection | Cable 3 m with connector, without armor |
