HEIDENHAIN 312 216-05 ROC 413 Singleturn Absolute Rotary Encoder EnDat
- Brand
- HEIDENHAIN
- Model
- 312 216-05
- GEARWELL SKU
- GWP-000023238
- Category
- Encoders & Position
Key specifications
- Mounting
- Synchro flange
- ID number
- 312216-05
- Resolution
- 13 bit = 8192 positions/revolution
- Power supply
- 5 V
- Data interface
- EnDat (synchronous serial), pure binary code
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HEIDENHAIN 312 216-05 ROC 413 Singleturn Absolute Rotary Encoder EnDat |
|---|---|
| Brand | HEIDENHAIN |
| Model | 312 216-05 |
| Category | Encoders & Position |
| Mounting | Synchro flange |
| ID number | 312216-05 |
| Resolution | 13 bit = 8192 positions/revolution |
| Power supply | 5 V |
| Data interface | EnDat (synchronous serial), pure binary code |
| Output signals | 1 Vpp sinusoidal, 2048 signal periods |
| Shaft diameter | 10 mm |
| Electrical connection | Cable 1 m with coupling, radial outlet |
| Operating temperature | -20 to +100 °C |
