Gems LS-3 PN173250 LS-3F4 PVDF Single-Point Level Switch
- Brand
- Gems
- Model
- LS-3 PN173250
- GEARWELL SKU
- GWP-000021476
- Category
- Pressure, Flow & Temperature
Key specifications
- Switch
- SPST 20 VA, 120-240 VAC
- Mounting
- 1/8 in NPT
- Part number
- 173250
- Pressure max.
- 50 psi (3 bar) @ 70 F
- Float diameter
- 1 in
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Gems LS-3 PN173250 LS-3F4 PVDF Single-Point Level Switch |
|---|---|
| Brand | Gems |
| Model | LS-3 PN173250 |
| Category | Pressure, Flow & Temperature |
| Switch | SPST 20 VA, 120-240 VAC |
| Mounting | 1/8 in NPT |
| Part number | 173250 |
| Pressure max. | 50 psi (3 bar) @ 70 F |
| Float diameter | 1 in |
| Actuation level | 1/2 in (12.7 mm) |
| Type designation | LS-3F4 |
| Operating temperature | -40 to +250 F (-40 to +121 C) |
| Min. liquid specific gravity | 0.86 |
| Stem / mounting / float material | PVDF |
