Gems GH3112-S30 GH Series Subminiature 3-Way Solenoid Valve
- Brand
- Gems
- Model
- GH3112-S30
- GEARWELL SKU
- GWP-000021475
- Category
- Valves & Manifolds
Key specifications
- CV
- 0.018
- MOPD
- 200 psig
- Power rating
- 2 W
- Primary prefix
- GH3112 - 3-way N.C. line connection, 303 stainless steel
- Standard ports
- #10-32 straight thread
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Gems GH3112-S30 GH Series Subminiature 3-Way Solenoid Valve |
|---|---|
| Brand | Gems |
| Model | GH3112-S30 |
| Category | Valves & Manifolds |
| CV | 0.018 |
| MOPD | 200 psig |
| Power rating | 2 W |
| Primary prefix | GH3112 - 3-way N.C. line connection, 303 stainless steel |
| Standard ports | #10-32 straight thread |
| Code suffix "S30" | as collected; not listed in the official model-number table |
| Orifice (body / stop) | 0.032 / 0.032 in |
