FESTO VTUG-10-VRPT-B1T-Q10B-UB-QH6SU-16K+SC Valve Terminal
- Brand
- FESTO
- Model
- VTUG-10-VRPT-B1T-Q10B-UB-QH6SU-16K+SC
- GEARWELL SKU
- GWP-000024801
- Category
- Valves & Manifolds
Key specifications
- Size
- 10 (VTUG-10)
- Exhaust (UB)
- Silencer, underneath
- Code suffix "+SC"
- as collected; not listed in the official model-number table
- Valve positions (16K)
- 16 x K = 2x3/2-way valve, normally closed
- Valve control (V/R/PT)
- Interface for fieldbus module, holding current reduction, I-Port interface
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FESTO VTUG-10-VRPT-B1T-Q10B-UB-QH6SU-16K+SC Valve Terminal |
|---|---|
| Brand | FESTO |
| Model | VTUG-10-VRPT-B1T-Q10B-UB-QH6SU-16K+SC |
| Category | Valves & Manifolds |
| Size | 10 (VTUG-10) |
| Exhaust (UB) | Silencer, underneath |
| Code suffix "+SC" | as collected; not listed in the official model-number table |
| Valve positions (16K) | 16 x K = 2x3/2-way valve, normally closed |
| Valve control (V/R/PT) | Interface for fieldbus module, holding current reduction, I-Port interface |
| Supply connection (Q10B) | Push-in connector 10 mm, underneath |
| Valve connection (QH6SU) | Push-in 6 mm with M7 thread, screwed, underneath straight outlet |
| Festo part number (configurable base) | 573606 |
| Valve type / voltage / manual override (B1T) | Sub-base valve, 24 V DC, non-detenting (detenting with accessories) |
