CKD AB41-03-3-B-AC220V AB41 Direct Acting 2-Port Solenoid Valve
- Brand
- CKD
- Model
- AB41-03-3-B-AC220V
- GEARWELL SKU
- GWP-000024916
- Category
- Valves & Manifolds
Key specifications
- Weight
- 0.45 kg
- Function
- 2-port, NC (open when energized)
- Body/seal
- Copper alloy / fluoro rubber (code B)
- Port size
- Rc3/8 (code 03)
- Coil housing
- Grommet lead wire (standard)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | CKD AB41-03-3-B-AC220V AB41 Direct Acting 2-Port Solenoid Valve |
|---|---|
| Brand | CKD |
| Model | AB41-03-3-B-AC220V |
| Category | Valves & Manifolds |
| Weight | 0.45 kg |
| Function | 2-port, NC (open when energized) |
| Body/seal | Copper alloy / fluoro rubber (code B) |
| Port size | Rc3/8 (code 03) |
| Coil housing | Grommet lead wire (standard) |
| Orifice size | 3 (code 3) mm |
| Code suffix "AC220V" | as collected; standard grommet-coil voltages are 100/200 VAC (200 VAC coil usable at 220 VAC 60 Hz per catalogue note) |
| Max. working pressure | 5 MPa |
| Apparent power, holding (50/60 Hz) | 18/15 VA |
| Max. working pressure differential (air, AC) | 1.5 MPa |
