GE UR-6A-V Multilin UR Digital I/O Module, Vertical Units
- Brand
- GE
- Model
- UR-6A-V
- GEARWELL SKU
- GWP-000025108
- Category
- PLCs & I/O
Key specifications
- Evidence
- GE Multilin F60 instruction manual 1601-0093-AB2 (GEK-119618A), Table 2-9 UR order codes for replacement modules, vertical units (hosted at na.eventscloud.com)
- Module type
- 6A: 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 contact inputs
- Seller code
- UR6AV
- Form-A operate time
- < 4 ms
- Mounting / coating code
- V = vertical units (3/4 rack), standard
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE UR-6A-V Multilin UR Digital I/O Module, Vertical Units |
|---|---|
| Brand | GE |
| Model | UR-6A-V |
| Category | PLCs & I/O |
| Evidence | GE Multilin F60 instruction manual 1601-0093-AB2 (GEK-119618A), Table 2-9 UR order codes for replacement modules, vertical units (hosted at na.eventscloud.com) |
| Module type | 6A: 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 contact inputs |
| Seller code | UR6AV |
| Form-A operate time | < 4 ms |
| Mounting / coating code | V = vertical units (3/4 rack), standard |
| Form-A carry continuous | 6 A |
| Form-C carry continuous | 8 A |
| Contact input wet contacts | 300 V DC maximum |
| Replacement module order code | UR-6A-V (format UR-**-*) |
| Contact input selectable thresholds | 17 V, 33 V, 84 V, 166 V |
