GE T35E00VFHF8FH6AM8HP6E Multilin T35 Transformer Protection Relay
- Brand
- GE
- Model
- T35E00VFHF8FH6AM8HP6E
- GEARWELL SKU
- GWP-000026261
- Category
- Machine Safety & Vision
Key specifications
- Mount (V)
- Vertical (3/4 size) - standard
- Evidence
- GE Vernova Multilin T35 brochure GEA-12671O (ordering table)
- Power supply (H)
- 125 / 250 V AC/DC
- User interface (F)
- Vertical front panel with English display
- Code position "E" (CPU)
- as collected; not listed in the current official T35 order-code table (current CPU options T/U/V/W)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE T35E00VFHF8FH6AM8HP6E Multilin T35 Transformer Protection Relay |
|---|---|
| Brand | GE |
| Model | T35E00VFHF8FH6AM8HP6E |
| Category | Machine Safety & Vision |
| Mount (V) | Vertical (3/4 size) - standard |
| Evidence | GE Vernova Multilin T35 brochure GEA-12671O (ordering table) |
| Power supply (H) | 125 / 250 V AC/DC |
| User interface (F) | Vertical front panel with English display |
| Code position "E" (CPU) | as collected; not listed in the current official T35 order-code table (current CPU options T/U/V/W) |
| Software options (00) | No software options |
| Slot P digital I/O (6E) | 4 Form-C outputs, 8 digital inputs |
| Order code (as collected) | T35-E00-VFH-F8F-H6A-M8H-P6E |
| Code positions "F8F", "M8H" (CT/VT) | as collected; not listed in the current official table (current CT/VT options 8L/8M/8N/8R) |
| Code position "H6A" (digital I/O) | as collected; 6A = 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 contact inputs per UR replacement-module table; not in the current T35 slot list |
