GE IC697PWR748D Series 90-70 48 VDC 90 W Power Supply Module
- Brand
- GE
- Model
- IC697PWR748D
- GEARWELL SKU
- GWP-000025876
- Category
- Power Supplies
Key specifications
- Outputs
- +5 VDC up to 18 A; +12 VDC up to 1.5 A; -12 VDC up to 1 A
- Evidence
- GE Fanuc GFK-1061D (hosted at qualitrol.com)
- Input power
- 160 W max at full load
- Output power
- 90 W max (all 3 outputs)
- Code suffix "D"
- as collected; GE catalog-number version/revision suffix on base IC697PWR748 (GE documents use letter suffixes for hardware/firmware versions); not listed separately in the official model table
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC697PWR748D Series 90-70 48 VDC 90 W Power Supply Module |
|---|---|
| Brand | GE |
| Model | IC697PWR748D |
| Category | Power Supplies |
| Outputs | +5 VDC up to 18 A; +12 VDC up to 1.5 A; -12 VDC up to 1 A |
| Evidence | GE Fanuc GFK-1061D (hosted at qualitrol.com) |
| Input power | 160 W max at full load |
| Output power | 90 W max (all 3 outputs) |
| Code suffix "D" | as collected; GE catalog-number version/revision suffix on base IC697PWR748 (GE documents use letter suffixes for hardware/firmware versions); not listed separately in the official model table |
| Nominal input | 48 VDC |
| Ride-through time | 10 ms minimum |
| Input voltage range | 35 to 60 VDC |
