GE IC697PWR711M Series 90-70 100 W AC/DC Power Supply Module
- Brand
- GE
- Model
- IC697PWR711M
- GEARWELL SKU
- GWP-000025873
- Category
- Power Supplies
Key specifications
- Outputs
- +5 VDC up to 20 A; +12 VDC up to 2 A; -12 VDC up to 1 A
- Evidence
- GE Fanuc GFK-1448B, IC697PWR711/713 version H and later (hosted at qualitrol.com)
- Holdup time
- 21 ms minimum
- Output power
- 100 W max (all 3 outputs)
- Power factor
- > 0.93
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC697PWR711M Series 90-70 100 W AC/DC Power Supply Module |
|---|---|
| Brand | GE |
| Model | IC697PWR711M |
| Category | Power Supplies |
| Outputs | +5 VDC up to 20 A; +12 VDC up to 2 A; -12 VDC up to 1 A |
| Evidence | GE Fanuc GFK-1448B, IC697PWR711/713 version H and later (hosted at qualitrol.com) |
| Holdup time | 21 ms minimum |
| Output power | 100 W max (all 3 outputs) |
| Power factor | > 0.93 |
| Code suffix "M" | as collected; GE catalog-number version/revision suffix on base IC697PWR711 (GE documents use letter suffixes for hardware/firmware versions); not listed separately in the official model table |
| Nominal input | 120/240 VAC or 125 VDC |
| Input voltage range | 90 to 264 VAC 47-63 Hz; 100 to 150 VDC |
| Operating temperature | 0 to 60 C |
