GE 239-RTD-AN Multilin 239 Motor Protection Relay
- Brand
- GE
- Model
- 239-RTD-AN
- GEARWELL SKU
- GWP-000025146
- Category
- Machine Safety & Vision
Key specifications
- IP class
- 40
- Order code
- 239-RTD-AN
- Ship weight
- 2.3 kg
- Communications
- RS485 2-wire, Modbus RTU, 1200-19,200 bps
- RTD option (RTD)
- 3 RTDs, stator/bearing; programmable platinum, nickel, copper
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE 239-RTD-AN Multilin 239 Motor Protection Relay |
|---|---|
| Brand | GE |
| Model | 239-RTD-AN |
| Category | Machine Safety & Vision |
| IP class | 40 |
| Order code | 239-RTD-AN |
| Ship weight | 2.3 kg |
| Communications | RS485 2-wire, Modbus RTU, 1200-19,200 bps |
| RTD option (RTD) | 3 RTDs, stator/bearing; programmable platinum, nickel, copper |
| Overload curves | 15 curves, fixed shape |
| Operating temperature | 0 to 60 °C |
| Analog output option (AN) | single isolated, 0-1 / 0-20 / 4-20 mA |
