FOTEK SSR-F-25DA-H SSR-F-DA Fuse Type Solid State Relay 16 A
- Brand
- FOTEK
- Model
- SSR-F-25DA-H
- GEARWELL SKU
- GWP-000023640
- Category
- Contactors & Starters
Key specifications
- Type
- High voltage type, DC to AC
- Ambient
- -40 to +80 °C; 35-85 % RH
- Fuse current
- 25 A
- Input voltage
- 4-32 VDC
- Response time
- 8.3 ms (60 Hz)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK SSR-F-25DA-H SSR-F-DA Fuse Type Solid State Relay 16 A |
|---|---|
| Brand | FOTEK |
| Model | SSR-F-25DA-H |
| Category | Contactors & Starters |
| Type | High voltage type, DC to AC |
| Ambient | -40 to +80 °C; 35-85 % RH |
| Fuse current | 25 A |
| Input voltage | 4-32 VDC |
| Response time | 8.3 ms (60 Hz) |
| Control method | zero cross |
| Max. load current | 16 A |
| Turn-off voltage | < 3.5 VDC |
| Isolation strength | 4 kVrms |
| Max. rated load voltage | 90-480 VAC |
