FOTEK SSR-50DA-H SSR-DA Series Single-Phase Solid State Relay
- Brand
- FOTEK
- Model
- SSR-50DA-H
- GEARWELL SKU
- GWP-000021110
- Category
- Contactors & Starters
Key specifications
- Type
- high voltage type, DC to AC
- Input voltage
- 4~32 VDC
- Response time
- 8.3 ms (60 Hz)
- Control method
- zero cross
- Max. load current
- 50 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK SSR-50DA-H SSR-DA Series Single-Phase Solid State Relay |
|---|---|
| Brand | FOTEK |
| Model | SSR-50DA-H |
| Category | Contactors & Starters |
| Type | high voltage type, DC to AC |
| Input voltage | 4~32 VDC |
| Response time | 8.3 ms (60 Hz) |
| Control method | zero cross |
| Max. load current | 50 A |
| Turn-off voltage | < 3.5 VDC |
| Operating ambient | -40~80 °C; 35~85% RH |
| Isolation strength | 4 kVrms |
| Rated load voltage | 90~480 VAC |
