FOTEK H5M-4DN H5M-4D Series Multi-Function Digital Timer
- Brand
- FOTEK
- Model
- H5M-4DN
- GEARWELL SKU
- GWP-000021094
- Category
- PLCs & I/O
Key specifications
- Output
- Relay, 10 A; N/R output control selectable
- Display
- 4 digits, 0~9999, 0.36 in red LED
- Mounting
- Panel mounting, 48x48, fixing hole 45x45 mm
- Base type
- H5M-4D
- DC output
- 60 mA / 12 VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK H5M-4DN H5M-4D Series Multi-Function Digital Timer |
|---|---|
| Brand | FOTEK |
| Model | H5M-4DN |
| Category | PLCs & I/O |
| Output | Relay, 10 A; N/R output control selectable |
| Display | 4 digits, 0~9999, 0.36 in red LED |
| Mounting | Panel mounting, 48x48, fixing hole 45x45 mm |
| Base type | H5M-4D |
| DC output | 60 mA / 12 VDC |
| Power supply | 90~250 VAC 50/60 Hz |
| Code suffix "N" | as collected; not listed in the official model-number table |
| Memory method | EEPROM |
| Control method | 10 modes, up or down timing |
| Operating ambient | -20 ~ +60 °C, 35 ~ 85% RH |
