FOTEK H5B-M3-24V H5B Series Multi-Range Power-On Delay Timer
- Brand
- FOTEK
- Model
- H5B-M3-24V
- GEARWELL SKU
- GWP-000021023
- Category
- PLCs & I/O
Key specifications
- Mounting
- Panel mounting, DIN 48x48, fixing hole 45x45 mm
- Model key
- H5B-M3-□□V ("□□V" = supply voltage)
- Reset time
- 0.1 s max.
- Time ranges
- 3S / 30S / 3M / 30M (multi-range)
- Control output
- Relay, 10 A contact rating
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK H5B-M3-24V H5B Series Multi-Range Power-On Delay Timer |
|---|---|
| Brand | FOTEK |
| Model | H5B-M3-24V |
| Category | PLCs & I/O |
| Mounting | Panel mounting, DIN 48x48, fixing hole 45x45 mm |
| Model key | H5B-M3-□□V ("□□V" = supply voltage) |
| Reset time | 0.1 s max. |
| Time ranges | 3S / 30S / 3M / 30M (multi-range) |
| Control output | Relay, 10 A contact rating |
| Repeat accuracy | 0.2% of F.S. max. |
| Setting accuracy | 5% of F.S. max. |
| Operating ambient | -20 ~ +60 °C, 35 ~ 85% RH |
| Power consumption | 3 VA max. |
| Supply voltage code | 24V |
