FESTO DGPL-32-1390-PPV-A-B-KF-SH-CS DGPL Linear Drive
- Brand
- FESTO
- Model
- DGPL-32-1390-PPV-A-B-KF-SH-CS
- GEARWELL SKU
- GWP-000021491
- Category
- Linear & Rotary Motion
Key specifications
- Guide
- KF: recirculating ball bearing guide
- Stroke
- 1390 (variable-stroke range 10-3000) mm
- Cushioning
- PPV: pneumatic, adjustable at both ends
- Code suffix "CS"
- as collected; not listed in the official model-number table
- Piston diameter
- 32 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FESTO DGPL-32-1390-PPV-A-B-KF-SH-CS DGPL Linear Drive |
|---|---|
| Brand | FESTO |
| Model | DGPL-32-1390-PPV-A-B-KF-SH-CS |
| Category | Linear & Rotary Motion |
| Guide | KF: recirculating ball bearing guide |
| Stroke | 1390 (variable-stroke range 10-3000) mm |
| Cushioning | PPV: pneumatic, adjustable at both ends |
| Code suffix "CS" | as collected; not listed in the official model-number table |
| Piston diameter | 32 mm |
| Operating pressure | 2-8 bar |
| Pneumatic connection | G1/8 |
| Slide attachment position | SH: slide, rear |
| Theoretical force at 6 bar | 483 N |
| Variable-stroke base product | DGPL-32-…-PPV-A-KF-B, part number 161793 |
