FESTO DGPL-18-300-PPV-A-KF DGPL Linear Drive with Guide
- Brand
- FESTO
- Model
- DGPL-18-300-PPV-A-KF
- GEARWELL SKU
- GWP-000021490
- Category
- Linear & Rotary Motion
Key specifications
- Guide
- Recirculating ball bearing guide
- Stroke
- 300 (variable-stroke range 10-1800) mm
- Cushioning
- Pneumatic, adjustable at both ends
- Piston diameter
- 18 mm
- Operating pressure
- 2-8 bar
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FESTO DGPL-18-300-PPV-A-KF DGPL Linear Drive with Guide |
|---|---|
| Brand | FESTO |
| Model | DGPL-18-300-PPV-A-KF |
| Category | Linear & Rotary Motion |
| Guide | Recirculating ball bearing guide |
| Stroke | 300 (variable-stroke range 10-1800) mm |
| Cushioning | Pneumatic, adjustable at both ends |
| Piston diameter | 18 mm |
| Operating pressure | 2-8 bar |
| Pneumatic connection | M5 |
| Theoretical force at 6 bar | 153 N |
| Variable-stroke base product | DGPL-18-…-PPV-A-KF-B, part number 161977 (collected code has no generation letter B) |
