EUCHNER RGBF02D12-502-M Industrial Sensor
- Brand
- EUCHNER
- Model
- RGBF02D12-502-M
- GEARWELL SKU
- GWP-000000772
- Category
- Industrial Automation Parts
Key specifications
- Contact
- Silver alloy, gold flashed
- Housing
- Die-cast aluminum, anodized
- Gross weight
- 0,702kg
- Actuating force
- min. 20 N
- Number NC contacts
- 2
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The EUCHNER RGBF02D12-502-M is an RGBF series precision multiple limit switch in an upright housing according to DIN 43697, with chisel plungers at a plunger spacing of 12 mm. It carries 2 switching elements ES 502 E, each a snap-action contact with 1 NC + 1 NO, for a total of 2 NC and 2 NO contacts. Contacts are rated AC-15 6 A 230 V, DC-13 6 A 24 V and AC-12 8 A 250 V, with a thermal rated current of 8 A. The anodized die-cast aluminum housing has 4 cable entries M25 x 1.5, IP67 protection and an ambient temperature range of -5 to 80 °C.
Technical reference
| Product name | EUCHNER RGBF02D12-502-M Industrial Sensor |
|---|---|
| Brand | EUCHNER |
| Model | RGBF02D12-502-M |
| Category | Industrial Automation Parts |
| Contact | Silver alloy, gold flashed |
| Housing | Die-cast aluminum, anodized |
| Gross weight | 0,702kg |
| Actuating force | min. 20 N |
| Number NC contacts | 2 |
| Ambient temperature | -5 ... 80 °C |
| Degree of protection | IP67 |
| Connection cross section | 0.34 ... 1.5 mm² |
