EUCHNER 091458 Industrial Sensor
- Brand
- EUCHNER
- Model
- 091458
- GEARWELL SKU
- GWP-000003404
- Category
- Industrial Automation Parts
Key specifications
- Dimensions
- according to EN 60947-5-2: (LxWxH) 131x40x40
- Connection type
- M12 plug connector, 8-pin; shield can be connected
- Current consumption
- 80 mA
- Degree of protection
- IP65/IP67
- DC-13 Safety outputs LA / LB
- 24V 400mA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The EUCHNER CES-A-C5H-01 is a CES-A transponder-coded non-contact safety switch with unicode evaluation: each actuator is uniquely coded and only taught-in actuators are detected, and further actuators can be taught in. Two redundant p-switching semiconductor safety outputs LA and LB rated DC-13 24V 400mA and a semiconductor monitoring output are provided, and the switch runs on 24 V DC with a current consumption of 80 mA. Connection is by an 8-pin M12 plug connector on a 131x40x40 PBT plastic housing with IP65/IP67 protection and an ambient range of -20 to 55 °C. It is suitable for category 4 / PL e, and with actuator CES-A-BBA the switch-on distance is 20 mm and the secured switch-off distance 40 mm.
Technical reference
| Product name | EUCHNER 091458 Industrial Sensor |
|---|---|
| Brand | EUCHNER |
| Model | 091458 |
| Category | Industrial Automation Parts |
| Dimensions | according to EN 60947-5-2: (LxWxH) 131x40x40 |
| Connection type | M12 plug connector, 8-pin; shield can be connected |
| Current consumption | 80 mA |
| Degree of protection | IP65/IP67 |
| DC-13 Safety outputs LA / LB | 24V 400mA |
| (external) operating voltage | 0.25 ... 8 A |
| EMC protection requirements | Acc. to EN IEC 60947-5-3 |
| (between the operating points of both safety outputs) | max. 120 ms |
