EUCHNER 084432 Industrial Sensor
- Brand
- EUCHNER
- Model
- 084432
- GEARWELL SKU
- GWP-000001858
- Category
- Industrial Automation Parts
Key specifications
- Gross weight
- 2,069kg
- Escape release
- None
- Switch bracket
- Steel powder-coated
- Detent mechanism
- None
- Item designation
- RIEGEL TP-C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The EUCHNER RIEGEL TP-C is a steel bolt for EUCHNER GP and TP safety switches, order no. 084432, for hinged and sliding doors hinged on the left with a door gap of about 15 mm. The switch is mounted for approach direction C; the bolt parts and actuator are supplied, and the safety switch is ordered separately. An integrated lockout bar lets the bolt be secured open with padlocks so nobody is locked into the danger area. It has a galvanized steel base plate, a powder-coated steel switch bracket and plastic guide strips and handle, and it must not be combined with an escape release.
Technical reference
| Product name | EUCHNER 084432 Industrial Sensor |
|---|---|
| Brand | EUCHNER |
| Model | 084432 |
| Category | Industrial Automation Parts |
| Gross weight | 2,069kg |
| Escape release | None |
| Switch bracket | Steel powder-coated |
| Detent mechanism | None |
| Item designation | RIEGEL TP-C |
| Approach direction | C |
| Storage temperature | -25 ... 70 °C |
| Number of safety switches that can be mounted | 1 |
