Endress+Hauser CPS41E-AA7BSB2 Memosens CPS41E Digital pH Sensor
- Brand
- Endress+Hauser
- Model
- CPS41E-AA7BSB2
- GEARWELL SKU
- GWP-000022465
- Category
- Pressure, Flow & Temperature
Key specifications
- Shaft
- Ø12 mm; lengths 120, 225, 360, 425 mm
- Series
- Memosens CPS41E
- Connection
- Memosens 2.0 inductive digital head
- Measuring range
- pH 1 to 12 (application A) / pH 0 to 14 (application B)
- Process pressure
- 0.8 to 11 bar abs
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Endress+Hauser CPS41E-AA7BSB2 Memosens CPS41E Digital pH Sensor |
|---|---|
| Brand | Endress+Hauser |
| Model | CPS41E-AA7BSB2 |
| Category | Pressure, Flow & Temperature |
| Shaft | Ø12 mm; lengths 120, 225, 360, 425 mm |
| Series | Memosens CPS41E |
| Connection | Memosens 2.0 inductive digital head |
| Measuring range | pH 1 to 12 (application A) / pH 0 to 14 (application B) |
| Process pressure | 0.8 to 11 bar abs |
| Reference system | Liquid KCl, ceramic zirconium dioxide junction |
| Ingress protection | IP68 |
| Temperature sensor | NTC 30K |
| Code suffix "-AA7BSB2" | as collected; not listed in an opened official model-number table |
| Process temperature | -15 to 80 (A) / 0 to 135 (B) °C |
| Order code (as collected) | CPS41E-AA7BSB2 |
