EATON MTL5573 MTL5500 Temperature Converter, THC or RTD Input
- Brand
- EATON
- Model
- MTL5573
- GEARWELL SKU
- GWP-000022829
- Category
- Pressure, Flow & Temperature
Key specifications
- Input
- Thermocouple, mV or RTD (2/3/4-wire)
- Channels
- 1
- Evidence
- Eaton EPS 45/5500 Rev 14 (hosted at core.instrumart.com)
- Brand note
- MTL (Eaton MTL intrinsic safety)
- Output range
- 4 to 20 mA nominal into 600 Ω max.
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | EATON MTL5573 MTL5500 Temperature Converter, THC or RTD Input |
|---|---|
| Brand | EATON |
| Model | MTL5573 |
| Category | Pressure, Flow & Temperature |
| Input | Thermocouple, mV or RTD (2/3/4-wire) |
| Channels | 1 |
| Evidence | Eaton EPS 45/5500 Rev 14 (hosted at core.instrumart.com) |
| Brand note | MTL (Eaton MTL intrinsic safety) |
| Output range | 4 to 20 mA nominal into 600 Ω max. |
| Response time | Typical 500 ms |
| Supply voltage | 20 to 35 V DC |
| Counterpart (backplane) | MTL4573 |
| Max. current consumption | 50 mA at 24 V (20 mA signal) |
