DELTA VFDB4185 VFDB brake units Braking Unit (Brake Module)
- Brand
- DELTA
- Model
- VFDB4185
- GEARWELL SKU
- GWP-000029952
- Category
- Variable Frequency Drives
Key specifications
- Max. motor capacity
- 185 kW
- Over-current level
- 340 A
- Mechanical configuration
- Wall-mounted enclosed type IP10
- Braking start-up voltage (DC)
- 618 / 642 / 667 / 690 / 725 / 750 ± 6 V
- Max. discharge current (10%ED)
- 225 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA VFDB4185 VFDB brake units Braking Unit (Brake Module) |
|---|---|
| Brand | DELTA |
| Model | VFDB4185 |
| Category | Variable Frequency Drives |
| Max. motor capacity | 185 kW |
| Over-current level | 340 A |
| Mechanical configuration | Wall-mounted enclosed type IP10 |
| Braking start-up voltage (DC) | 618 / 642 / 667 / 690 / 725 / 750 ± 6 V |
| Max. discharge current (10%ED) | 225 A |
| Continuous discharge current | 100 A |
| Min. equivalent resistor for each braking unit | 3.4 Ω |
