Mitsubishi Electric FR-F820-18.5K-1 FR-F800 Inverter (fan and pump, energy-saving)
- Brand
- Mitsubishi Electric
- Model
- FR-F820-18.5K-1
- GEARWELL SKU
- GWP-000030389
- Category
- Variable Frequency Drives
Key specifications
- Approx. mass
- 15.5 kg
- Type (monitor output)
- FM (terminal FM equipped model)
- Rated output current (LD)
- 70.5 A
- Rated output current (SLD)
- 77 A
- Applicable motor capacity (LD)
- 18.5 kW
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Mitsubishi Electric FR-F820-18.5K-1 FR-F800 Inverter (fan and pump, energy-saving) |
|---|---|
| Brand | Mitsubishi Electric |
| Model | FR-F820-18.5K-1 |
| Category | Variable Frequency Drives |
| Approx. mass | 15.5 kg |
| Type (monitor output) | FM (terminal FM equipped model) |
| Rated output current (LD) | 70.5 A |
| Rated output current (SLD) | 77 A |
| Applicable motor capacity (LD) | 18.5 kW |
| Applicable motor capacity (SLD) | 18.5 kW |
| Rated input AC voltage/frequency | Three-phase 200 to 240 V, 50/60 Hz |
| Circuit board coating / plated conductor | Without / without |
