DELTA VFD450C43E C2000 series AC Motor Drive
- Brand
- DELTA
- Model
- VFD450C43E
- GEARWELL SKU
- GWP-000029948
- Category
- Variable Frequency Drives
Key specifications
- Version E
- Built-in EMC filter (Frame A~C), built-in conduit box (Frame D and above)
- Rated voltage / frequency
- 3-phase AC 380 V ~ 480 V (-15% ~ +10%), 50 / 60 Hz
- Rated output current (Heavy Duty)
- 86 A
- Rated output current (Normal Duty)
- 91 A
- Applicable motor output (Normal Duty)
- 45 kW
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA VFD450C43E C2000 series AC Motor Drive |
|---|---|
| Brand | DELTA |
| Model | VFD450C43E |
| Category | Variable Frequency Drives |
| Version E | Built-in EMC filter (Frame A~C), built-in conduit box (Frame D and above) |
| Rated voltage / frequency | 3-phase AC 380 V ~ 480 V (-15% ~ +10%), 50 / 60 Hz |
| Rated output current (Heavy Duty) | 86 A |
| Rated output current (Normal Duty) | 91 A |
| Applicable motor output (Normal Duty) | 45 kW |
| Input current (Normal Duty / Heavy Duty) | 101 / 96 A |
