DELTA ECMA-CA1330S4 ECMA series (ASDA-A2) AC Servo Motor
- Brand
- DELTA
- Model
- ECMA-CA1330S4
- GEARWELL SKU
- GWP-000029809
- Category
- Servo Systems
Key specifications
- Model code
- C=220V/3000r/min, A=absolute encoder, 13=130mm, 30=3kW, S=keyway with screw hole, brake and oil seal, 4 (lineup ECMA-C△1330□4)
- Rated speed
- 3000 r/min
- Rated torque
- 9.55 N-m
- Maximum speed
- 4500 r/min
- Rated current
- 17.2 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ECMA-CA1330S4 ECMA series (ASDA-A2) AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECMA-CA1330S4 |
| Category | Servo Systems |
| Model code | C=220V/3000r/min, A=absolute encoder, 13=130mm, 30=3kW, S=keyway with screw hole, brake and oil seal, 4 (lineup ECMA-C△1330□4) |
| Rated speed | 3000 r/min |
| Rated torque | 9.55 N-m |
| Maximum speed | 4500 r/min |
| Rated current | 17.2 A |
| Maximum torque | 28.65 N-m |
| Maximum current | 47.5 A |
| Rated output power | 3.0 kW |
