DELTA ECM-B3M-C20807RS1 ECM-B3 (ASDA-B3 series motors) AC Servo Motor
- Brand
- DELTA
- Model
- ECM-B3M-C20807RS1
- GEARWELL SKU
- GWP-000012828
- Category
- Servo Systems
Key specifications
- Rated power
- 0.75 kW
- Rated torque
- 2.4 N-m
- Rated current
- 4.27 Arms
- Maximum torque
- 8.4 N-m
- Encoder type (code 2)
- 24-bit incremental magnetic optical encoder
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Delta ECM-B3M-C20807RS1 is a Delta ECM-B3 series medium-inertia AC servo motor for 220 V B3 series servo drives, with an 80 mm frame and a rated output of 0.75 kW. It gives 2.4 N-m rated and 8.4 N-m maximum torque at a rated speed of 3000 rpm and up to 6000 rpm, with 4.27 Arms rated and 15.8 Arms maximum current. The motor has a 24-bit incremental optical encoder, and the R shaft code means a keyway with fixed screw holes, an oil seal and no holding brake; the S code means a standard connector and standard shaft diameter. Rotor inertia is 1.07 (x10-4 kg.m2) and the weight is 2.34 kg.
Technical reference
| Product name | DELTA ECM-B3M-C20807RS1 ECM-B3 (ASDA-B3 series motors) AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECM-B3M-C20807RS1 |
| Category | Servo Systems |
| Rated power | 0.75 kW |
| Rated torque | 2.4 N-m |
| Rated current | 4.27 Arms |
| Maximum torque | 8.4 N-m |
| Encoder type (code 2) | 24-bit incremental magnetic optical encoder |
| Weight (without brake) | 2.34 kg |
| Max. instantaneous current | 15.8 Arms |
| Rated speed / Maximum speed | 3000 / 6000 rpm |
