DELTA ECM-A3L-CY040FSS1 ECM-A3 series (ASDA-A3) AC Servo Motor
- Brand
- DELTA
- Model
- ECM-A3L-CY040FSS1
- GEARWELL SKU
- GWP-000029794
- Category
- Servo Systems
Key specifications
- Model code
- C=220V/3000r/min, Y=24-bit absolute optical encoder, 04=40mm, 0F=50W, S=keyway with screw hole, with brake and oil seal, S=standard shaft, 1=standard product
- Rated speed
- 3000 r/min
- Rated torque
- 0.159 N-m
- Maximum speed
- 6000 r/min
- Rated current
- 0.66 Arms
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ECM-A3L-CY040FSS1 ECM-A3 series (ASDA-A3) AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECM-A3L-CY040FSS1 |
| Category | Servo Systems |
| Model code | C=220V/3000r/min, Y=24-bit absolute optical encoder, 04=40mm, 0F=50W, S=keyway with screw hole, with brake and oil seal, S=standard shaft, 1=standard product |
| Rated speed | 3000 r/min |
| Rated torque | 0.159 N-m |
| Maximum speed | 6000 r/min |
| Rated current | 0.66 Arms |
| Maximum torque | 0.557 N-m |
| Maximum current | 2.82 Arms |
| Rated output power | 0.05 kW |
