DELTA ECM-A3L-CY040FRS1 ECM-A3L AC Servo Motor
- Brand
- DELTA
- Model
- ECM-A3L-CY040FRS1
- GEARWELL SKU
- GWP-000029793
- Category
- Servo Systems
Key specifications
- Model code
- C: 220 V / 3,000 r/min; Y: 24-bit absolute optical encoder (single-turn 24-bit, multi-turn 16-bit); 04: 40 mm; 0F: 50 W; R: keyway with screw hole, without brake, with oil seal; S: standard shaft; 1: standard product
- Rated torque
- 0.159 N-m
- Rated current
- 0.66 Arms
- Maximum torque
- 0.557 N-m
- Maximum current
- 2.82 Arms
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ECM-A3L-CY040FRS1 ECM-A3L AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECM-A3L-CY040FRS1 |
| Category | Servo Systems |
| Model code | C: 220 V / 3,000 r/min; Y: 24-bit absolute optical encoder (single-turn 24-bit, multi-turn 16-bit); 04: 40 mm; 0F: 50 W; R: keyway with screw hole, without brake, with oil seal; S: standard shaft; 1: standard product |
| Rated torque | 0.159 N-m |
| Rated current | 0.66 Arms |
| Maximum torque | 0.557 N-m |
| Maximum current | 2.82 Arms |
| Rated output power | 0.05 kW |
| Weight (without brake) | 0.38 kg |
| Rated speed / maximum speed | 3000 / 6000 r/min |
