DELIXI XJD1-55KW 380V XJD1 Autotransformer Starter Box
- Brand
- DELIXI
- Model
- XJD1-55KW 380V
- GEARWELL SKU
- GWP-000021241
- Category
- Contactors & Starters
Key specifications
- Seller code
- XJD155
- Control mode
- automatic
- Rated voltage
- AC 380 V
- Type designation
- XJD1-55
- Outline dimensions
- 495 x 990 x 310 (A x B x C) mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELIXI XJD1-55KW 380V XJD1 Autotransformer Starter Box |
|---|---|
| Brand | DELIXI |
| Model | XJD1-55KW 380V |
| Category | Contactors & Starters |
| Seller code | XJD155 |
| Control mode | automatic |
| Rated voltage | AC 380 V |
| Type designation | XJD1-55 |
| Outline dimensions | 495 x 990 x 310 (A x B x C) mm |
| Max. working current | 105 A |
| Autotransformer power | 55 kW |
| Controlled motor power | 55 kW |
| Standard / certification | GB 14048.4 / CCC |
| Max. total starting time | 60 s |
| Motor protector setting (reference) | 105 A |
